ANDREW LDF4.5RK-50 Cable Heliax Superflexible de 5/8 Cobre Corrugado Con Forro Retardante al Fuego
Descripción
LDF4.5RK-50 ANDREW Cable Heliax Superflexible de 5/8 Cobre Corrugado Con Forro Retardante al Fuego
Electrical Specifications
| Cable Impedance | 50 ohm ±1 ohm |
| Capacitance | 76 pF/m 23.165 pF/ft |
| dc Resistance Inner Conductor | 0.722 ohms/km 0.22 ohms/kft |
| dc Resistance Outer Conductor | 1.378 ohms/km 0.42 ohms/kft |
| dc Test Voltage | 5000 V |
| Inductance | 0.187 µH/m 0.057 µH/ft |
| Insulation Resistance | 100000 MOhms-km |
| Jacket Spark Test Voltage (rms) | 8000 V |
| Operating Frequency Band | 1 – 6100 MHz |
| Peak Power | 62 kW |
Velocity PRECIO POR METRO | 88 % |
10-09-2025 03:40:33 SSN2 U-16-Gn 203675
