SUPREMA BMS3 Biomini slim3 Lector enrolador de huella USB
Descripción
BMS3 SUPREMA Biomini slim3 Lector enrolador de huella USB
Specifications
- Sensor & Image
- Capture
Flat(Single) fingers
- Sensor Type
Optical
- Resolution
500 ppi
- Grayscale
8-bit 256 levels
- Image Size (WxL)
400 x 500 pixels
- Template Format
Xperix ISO19794-2 ANSI 378
- Supported Image Formats
RAW BMP ISO 19794-4 WSQ(FBI certified)
- Encryption
Device: AES-256 RSA 1024bit ECC 521bit
SDK: AES-256 - FBI / Image Certifications
Mobile ID FAP 30 (PIV-071006) PIV Single Finger (PIV-071006) FIPS
- System
- OS Support
Windows 7 or higher 32/64bit
Linux Ubuntu Debian Fedora OpenSUSE CentOS 32/64bit
Android 5.0 or higher (USB Host)
OS/Platform Independent Stand-alone Operation
- Weight & Dimensions
- Weight
111 g
- Platen Size (WxL)
21.5 mm x 26.5 mm
- Sensing Area (WxL)
20.32 mm x 25.4 mm
- Dimensions (WxLxH)
83 mm x 45.9 mm x 20 mm
- Durability
- Suface Protection
Optic Glass (Scratch free)
- Ingress Protection
IP65 (Sealed between bezel and sensor surface)
- Operating Temperature
-10 °C - 50 °C (14 - 122 )
- Operating Humidity
0% - 90% non-condensing
- Power & Connectors
- Interface
USB 2.0 High Speed
- Power Source
USB Host
- USB Voltage Level
5.0V ±10%
- General
- Live Finger Detection(LFD)
Supported (by AI-based)
- Plug & Play
Supported (by HID Protocol)
- Stand-alone Mode
Supported
- Multi Dynamic Range(MDR)
Supported
- Certification
- Certification
FBI CE FCC KC RoHS USB-IF CB IEC 62471 WEEE REACH BIS WHQL
- Card
- Contact Smart Card
Not Supported
- Contactless Smart Card
Not Supported
- SAM Slot
Not Supported
- Security
- TPM
Not Supported
Nota . En el caso de uso de profesioanles en desarrollo de software considerar SDK.
Nota.- EL SDK tiene costo.
