SUPREMA BMS3 Biomini slim3 Lector enrolador de huella USB
Descripción
BMS3 SUPREMA Biomini slim3 Lector enrolador de huella USB
<-- Seccin de ttulo --> <-- Seccin de especificaciones en cards --> <-- Notas --> <-- Separador -->
Specifications
Sensor & Image
- Capture: Flat(Single) fingers
- Sensor Type: Optical
- Resolution: 500 ppi
- Grayscale: 8-bit 256 levels
- Image Size (WxL): 400 x 500 pixels
- Template Format: Xperix ISO19794-2 ANSI 378
- Supported Image Formats: RAW BMP ISO 19794-4 WSQ(FBI certified)
- Encryption: Device: AES-256 RSA 1024bit ECC 521bit
SDK: AES-256 - FBI / Image Certifications: Mobile ID FAP 30 (PIV-071006) PIV Single Finger (PIV-071006) FIPS
System
- OS Support: Windows 7 or higher 32/64bit
Linux Ubuntu Debian Fedora OpenSUSE CentOS 32/64bit
Android 5.0 or higher (USB Host)
OS/Platform Independent Stand-alone Operation
Weight & Dimensions
- Weight: 111 g
- Platen Size (WxL): 21.5 mm x 26.5 mm
- Sensing Area (WxL): 20.32 mm x 25.4 mm
- Dimensions (WxLxH): 83 mm x 45.9 mm x 20 mm
Durability
- Surface Protection: Optic Glass (Scratch free)
- Ingress Protection: IP65 (Sealed between bezel and sensor surface)
- Operating Temperature: -10 C - 50 C (14 - 122 )
- Operating Humidity: 0% - 90% non-condensing
Power & Connectors
- Interface: USB 2.0 High Speed
- Power Source: USB Host
- USB Voltage Level: 5.0V 10%
General
- Live Finger Detection(LFD): Supported (by AI-based)
- Plug & Play: Supported (by HID Protocol)
- Stand-alone Mode: Supported
- Multi Dynamic Range(MDR): Supported
Certification
- Certification: FBI CE FCC KC RoHS USB-IF CB IEC 62471 WEEE REACH BIS WHQL
Card
- Contact Smart Card: Not Supported
- Contactless Smart Card: Not Supported
- SAM Slot: Not Supported
Security
- TPM: Not Supported
Nota: En el caso de uso de profesionales en desarrollo de software considerar SDK.
Nota: EL SDK tiene costo.
