TP-LINK CPE610 CPE de Exterior de 5 GHz a 300Mbps Antena direccional de 23dBi potencia de 27 dBm PoE pasivo

TP-LINK
$1,597.85 (incluye IVA) $1,930.50
Costo de envío no incluído, enviamos a todo Mexico. Sujeto a Cobertura.
TP-LINK
Stock 188
Código producto - SKU CPE610
Añadir a Favoritos
¿Cómo podemos ayudar?
Llámanos: +52 (33) 8000 0800 (Lunes-Viernes, 08:00-18:00)
Pregunta por los detalles
Mandanos un mensaje

Descripción

CPE610 TP-LINK CPE de Exterior de 5 GHz a 300Mbps Antena direccional de 23dBi potencia de 27 dBm PoE pasivo

<-- Seccin de caractersticas de hardware -->

CARACTERSTICAS DE HARDWARE

  • Procesador: Qualcomm 560MHz CPU MIPS 74Kc
  • Memoria: 64MB DDR2 RAM 8MB Flash
  • Interface: 1 10/100Mbps Shielded Ethernet Port (LAN/POE)
    1 Reset Button
  • Fuente de Alimentacin: Passive Power over Ethernet via LAN (4 5pins; -7 8pins)
    Voltage range: 16-27VDC
  • Dimensiones (W X D X H): 366 x 280 x 207 mm (14.4 x 11.0 x 8.1 in.)
  • Dimensiones: 360 x 280 x 207 mm (14.4 x 11.0 x 8.1 in.) (No mount)
  • Ganancia de Antena: 23dBi
  • Cobertura de Antena: 9(Azimuth) 7(Elevation)
  • Proteccin: 15KV ESD Protection
    6KV Lightning Protection
  • Cercado: Material: Outdoor PC stabilized plastic
    Weatherproof: IP65 water and dust proof design
<-- Seccin de caractersticas inalmbricas -->

CARACTERSTICAS INALMBRICAS

  • Estndares Inalmbricos: IEEE 802.11a/n
  • Protocolo Propietario: TDMA Mode (with Pharos MAXtream enabled)
  • Velocidades Inalmbricas: Up to 300Mbps (40MHz Dynamic)
    Up to 144.4Mbps (20MHz Dynamic)
    Up to 72.2Mbps (10MHz Dynamic)
    Up to 36.1Mbps (5MHz Dynamic)
  • Frecuencia: 5.155.85GHz
  • Potencia de Transmision: Max. 27dBm (Adjustable power by 1dBm)
<-- Seccin de caractersticas de software -->

CARACTERSTICAS DE SOFTWARE

  • Configuracion De Red: WAN: Static/Dynamic/PPPoE/L2TP/PPTP
    LAN: Static/Dynamic/DHCP
    Forwarding: ALG/UPnP/Virtual Server/Port Trigger
    Security: SPI Firewall/ Ping Forbidden/DoS Protection
    Access Control
    Static Routing
    Bandwidth Control
    IP & MAC Binding
  • Configuraciones Inalmbricas: Pharos MAXtream TDMA Technology
    Selectable Channel Width: 5/10/20/40MHz
    Auto Channel Selection
    Transmit Power Control
    Dynamic Frequency Selection(DFS)
    WDS Enable/Disable
    Security: WPA/WPA2 WPA-PSK/WPA2-PSK (AES/TKIP) Encryption
    64/128/152-bit WEP Encryption
    SSID Broadcast Enable/Disable
    Multi-SSID with VLAN Tagging(AP Mode only)
    Distance/ACK Timeout Setting
    Wireless MAC Address Filter
    Wireless Advanced:
    Beacon Interval/RTS Threshold/Fragmentation Threshold/DTIM Interval/AP Isolation/Short GI/Wi-Fi Multimedia
  • Administracin: Discovery and Remote Management via Pharos Control application
    HTTP/HTTPS Web-based management
    System log
    SNMP Agent(v2c)
    Ping Watch Dog
    Dynamic DDNS
    SSH Server
  • Herramientas de sistema: Indicators: Signal Strength/Noise/Transmit CCQ/CPU/Memory
    Monitors: Throughput/Stations/Interfaces/ARP/Routes/WAN/DHCP
    Spectrum Analyzer
    Speed Test
    Ping
    Traceroute
  • Optimizaciones a Nivel de Sistema: Optimized IGMP Snooping/Proxy for multicast applications
    Hardware watch dog
<-- Seccin de caractersticas del adaptador PoE -->

POE ADAPTER FEATURES

  • Dimensions(W x D x H): 85.843.929.7 mm
  • Interfaces: 1 AC Jack with Earth Ground
    1 10/100Mbps Shielded Ethernet Port (Power Data)
    1 10/100Mbps Shielded Ethernet Port (Data)
  • Botn: Remote Reset Button
  • Power Status LEDs: Green
  • Input: 100-240VAC 50/60Hz
  • Output: 24VDC 0.5A Max
    4 5pins; -7 8pins. (Support up to 60m Power over Ethernet)
  • Eficiencia: >84.29%
  • Certifications: CE/FCC/UL/IC/GS/PSB/C-tick/SAA/S-Mark/KC-mark
<-- Seccin de otros -->

OTROS

  • Certificacion: CE FCC RoHS IP65
  • Contenidos del Paquete: Outdoor Wireless CPE
    24V 0.5A Passive PoE Adapter
    Pole Mounting Straps
    AC Power Cord
    Installation Guide
  • Requisitos del Sistema: Microsoft Windows 98SE NT 2000 XP Vista or Windows 10 Windows 8 Windows 7 MAC OS NetWare UNIX or Linux.
    Note: We recommend you to use one of following Web browsers for an improved user experience: Google Chrome Safari and Firefox. IE browsers are not recommended.
  • Ambiente: Operating Temperature: -40C70C (-40F158F)
    Storage Temperature: -40C70C (-40F158F)
    Operating Humidity: 10%90% non-condensing
    Storage Humidity: 5%95% non-condensing
